What ARM 18067 Means

On a Case IH tractor, fault code ARM 18067 is an armrest controls fault. The official description is EHR 2 lever implausibility error.

In practical terms, the ARM controller has detected that the signal or operating state from the EHR 2 lever is not plausible. This usually means the controller is seeing information that does not match the expected lever behavior. The code does not, by itself, prove that the lever is the only failed part.

Likely Symptoms

Depending on the tractor configuration and when the fault occurs, an operator may notice one or more of the following:

  • ARM 18067 displayed on the tractor monitor or fault-code screen.
  • Warning light, message, or audible alert related to armrest controls.
  • The EHR 2 lever function may not respond normally.
  • The related hydraulic function may be limited, disabled, or intermittent.
  • The fault may appear only when the lever is moved, at start-up, or during certain operating conditions.

Possible Causes

Because the official fault only identifies an implausibility error, diagnosis should consider the whole lever input circuit rather than assuming a single failed part. Possible causes include:

  • Faulty or worn EHR 2 lever input device.
  • Lever not returning smoothly to its expected neutral position.
  • Damaged, loose, corroded, or contaminated electrical connector related to the lever circuit.
  • Wiring damage, poor contact, or intermittent open/short in the lever signal circuit.
  • Moisture, dirt, or debris affecting the lever mechanism or electrical connection.
  • Calibration, configuration, or software-related issue in the armrest control system.
  • Less commonly, an issue with the ARM controller input after other causes have been ruled out.

Diagnostic Checks

1. Confirm the Fault

Record the exact fault code, operating conditions, and whether the fault is active or stored. Note whether ARM 18067 appears at key-on, when moving the EHR 2 lever, or only during operation.

2. Check Lever Operation

With the tractor safely parked and following the operator manual, move the EHR 2 lever through its normal range. Look for sticking, binding, looseness, or failure to return normally. Do not force the lever if it feels jammed or damaged.

3. Inspect for Obvious Electrical Issues

Inspect accessible wiring and connectors associated with the armrest control and EHR 2 lever circuit for obvious damage, loose plugs, corrosion, moisture, or pinched harness sections. Do not probe connectors unless you have the correct service information and tools.

4. Look for Contamination or Moisture

If liquid, dirt, or debris has entered the control area, it may cause erratic lever signals. Clean only external surfaces as appropriate and avoid spraying cleaners or water into electrical controls.

5. Clear and Recheck Only After Inspection

If the tractor system allows fault clearing, clear the code only after recording it and checking for visible issues. Operate the lever under safe conditions and see whether ARM 18067 returns.

6. Use Dealer Diagnostics When Needed

Dealer diagnostic equipment may be required to view live lever input data, confirm whether the signal is plausible, perform calibrations, check controller configuration, or run guided tests. This is especially important if the fault is active, intermittent, or returns after basic checks.

Repair Guidance

Repairs should be based on test results, not on the fault code alone. Practical repair steps may include correcting loose or damaged connectors, repairing wiring faults, cleaning contamination where appropriate, recalibrating the control system if required, or replacing a confirmed faulty lever/input component.

If wiring repairs, lever replacement, calibration, or controller diagnosis is required, a qualified technician is recommended. Some repairs may require Case IH service information, correct test adapters, and diagnostic software to prevent misdiagnosis or damage to the armrest control system.

When to Stop and Call a Technician

Contact a Case IH dealer or qualified agricultural equipment technician if:

  • ARM 18067 is active and the related function is disabled.
  • The fault returns immediately after clearing.
  • The lever signal must be checked with live diagnostic data.
  • Calibration or controller configuration is required.
  • There is visible harness damage, corrosion, or suspected controller input failure.

Find Local Case IH Diagnostic Support

Key Takeaway

ARM 18067 on a Case IH tractor means the ARM controller has detected an EHR 2 lever implausibility error. Start with safe visual and operational checks, but use qualified service support when the problem involves electrical testing, calibration, or controller-level diagnostics.
